Vapomatic Veterinary Vaporizer


Designed with the veterinarian in mind, the Vapomatic veterinary vaporizer is a superior performing, agent specific calibrated anesthetic vaporizer. The temperature compensated Vapomatic, provides outstanding performance at the low flow rates commonly used for veterinary anesthesia.

The Vapomatic veterinary vaporizer is available in Isoflurane or Sevoflurane. Weighing only 7.5lbs when dry and has a liquid compacity of 200ml. Each vaporizer has standard 23mm inlet and outlet connections.  The connections provide flexibility to easily switch a circle system to non-rebreathing system by removing the outlet connection.

The safety of the surgical staff and the patient is extremely important. With that in mind, the Vapomatic veterinary vaporizer has specific safety features.  The color-coding of the Vapomatic matches the assigned color of the anesthetic gas. Another key point is the tamperproof seal.  The Vapomatic cannot be adjusted in the field.  Finally, the vaporizing chamber isolated and in the “OFF” position.

The Vapomatic requires annual calibration and service.  A.M. Bickford, Inc. provides customers a FREE Vapomatic Loaner to maintain your surgical schedule.

For nearly 50 years, A.M. Bickford’s veterinary anesthesia equipment and supplies have built a reputation of quality, safety, durability, and trust. So dependable, they wear our family name.

Bickford Vapomatic Vaporizer Flyer

Design & Features

■ Temperature compensated.

■ Output concentration stable during assisted respiration pressure pulses.

■ Filler-drain-contents window combined in easy access single unit.

■ Large dial with easy to see numbers has “off” lock and calibration indents.

■ Dial Rotation: CW to decrease and “off” CCaW for “on” and increase.

■ “Off” Position locks to prevent accidental actuation of vaporizer.

■ When “Off”, vaporizing chamber is isolated and gas is bypassed to outlet.

■ Tamper-proof adjustments – dial seal must be broken for access.

■ Sump may be removed for cleaning or wick replacement without disturbing calibration by removing one screw.

■ Inlet and Outlet fittings are standard 23mm male & female tapers and are individually replaceable. Other connector options are available upon request.

■ Mounting holes in rear are interchangeable with other vaporizers.

Vapomatic™ Performance & Specifications

  • Range of gas flow rates: 0.1 to 10 liters/minute.
  • Range of ambient temperatures: 60°F to 90°F.
  • Range of anesthetic concentration: 0.5% vol.
  • Models available for Isoflurane or Sevoflurane.
  • Calibration accuracy: ±.1% concentration or ±10% of dial setting at calibration points.
  • Liquid capacity (dry): Approximately 200 ml.
  • Weight (dry): Approximately 7.5 lb.


Vapomatic Vaporizer Calibration Service

A.M. Bickford recommends to service and calibrate your Vapomatic veterinary anesthetic vaporizer annually.  Click here to schedule calibration or receive a quote
